Below are some examples of Atech's core activities. We will tailor our deliverables to suit the requirements of the client's investment process.

We are flexible and we have a proven track record of delivering in full, on time, every time.

Cable and OHL Front End Design

We can provide pre-construction stage designs for electrical ratings and define spacings and electrical clearance requirements. Our designs go hand-in-hand with all available installation methodology, commissioning requirements and testing/inspection regimes.
Button
Cable and OHL Components and Equipment

We can fully detail out the equipment required for your cable or OHL project, some of which will need careful positioning along the route, based on the latest Design Specifications, British Standards and Euro Codes.
Button
Defining Survey Requirements

We can advise you on the appropriate level of instrusive and non-intrusive surveys. Once we have determined a good route design and our desktop studies have indicated what "should" be under the ground, we can overlay our installation methodology and tell you the type, location and quantity of ground investigation that is required in order to obtain the information needed to confidently progress to the next stage of your project.
Button

Construction Logistics and Sequencing

We can produce detailed "Stage by Stage" documentation to allow for quick reference to the proposed sequence of work, for any project, large or small. Activity durations and dependancies are carefully considered to define critical paths through the construction phase and to refresh design option choices as required.
Button
Construction Traffic Management

We can accurately quantify the amount and type of vehicle movements for any project, large or small. We specialise in linear projects such as overhead line new-builds and underground cable installation. We can prepare traffic management plans and advise on traffic routes, avoiding important public uses such as schools and emergency service routes.
Button
Installation Methodology

We can advise on how the proposed infrastructure should be constructed safely, quickly and reliably. The installation methods can then feedback into the design as part of an iterative process. Design detail and construction technique go hand-in-hand.
Button

Desktop Studies and Utility Searches

We can carry out full desktop searches for 3rd party surveys, unexploded ordnance, flood risk and sensitive land designations. From this we can develop a plan for further, more indepth surveys, both intrusive and non-intrusive. We can also carry out physical scans to build up a more accurate picture of what is below the ground.
Button
Constraint Mapping

We can create composite maps to visually represent the complexity of your proposed and/or rejected transmission infrastructure route options. This could be a "heat map," or simply an annotated plan to assist, recommend and document the key decisions to be made.
Button
Complex Cable Routing

We can confidently find a route through urban and rural areas, overcoming obstacles such as flood plains, water courses and weak/soft ground. We carefully consider existing infrastructure such as railway lines, tram lines and roads. We are always sensitive to land designations such as Special Areas of Conservation, Sites of Special Scientific Interest, European Habitats and Areas of Outstanding Natural Beauty.
